Stack.05 Plus

DS44

Hotter and sweetness than the Stack.05, this pickup has overwound coils for more aggressive sound and better attack. Its unique extended dual resonance design allows for better hi-end harmonics, especially when the amplifier gain increases. The lows are tight with a precise and articulate response that has just the right amount of high-end without sounding brittle. It has a coil that actually injects negative hum into the pickup circuit, making the model noiseless. The middle pickup is RWRP, reverse wind reverse polarity, for noise cancellation in the in-between 2 and 4 positions. This pickup is a drop-in for any single coil pickup and comes with a 2-conductor shielded wire.
Proudly made in Florida-BA, this pickup is hand built in our workshop and wax potted for squeal free operation.

  • OUTPUT: Moderate
  • DC RESISTANCE: 24,6K (neck, middle and bridge)
  • MAGNET: hand-beveled ALNICO V polepieces
  • RESONANCE PEAK: 2,96KHz (neck, middle and bridge)
  • INDUCTANCE: 5,49 Henries (neck, middle and bridge)
  • HUM CANCELLING: Yes
7
Bass
8
Mid
6
Treble
  • CABLE: 2-conductor shielded
  • PLASTIC COVER: white and black.
  • BASE: shielded CEM1 with two 6/32” brass treads for lifetime guarantee.
  • INCLUDED COMPONENTS: Mounting screws, pickup height adjustment tubing and wiring diagram.
